Led silicone sealant-Ordinary refractive index Encapsulants(SMD) BQ-4370-Dongguan City Betterly New Materials Co.,Ltd_

Home > Products > Light Source > LED >Other LEDs

Led silicone sealant-Ordinary refractive index Encapsulants(SMD) BQ-4370

MOQ ：1 piece

Lead Time ：7 Days

Inquiry Start Order

Seller Support : Trade Authenticity Guaranteed & Accepting

Payment : L/C，T/T，Western Union, Money Gram, Credit Card, Paypal

Product details

Supply Ability

Warranty(Year)：1 Year

Product Specifications

Product Description

Applications

LED SMD package

Use

1 Use the proportion: BQ-4370-1A: 1

BQ-4370-1B: 1;

(2) The A, B material was mixed to no knots, no lumps, a uniform thin thick homogeneous state (generally requires 5-8 minutes), placed under vacuum deaeration, until no bubbles up (pumping

Vacuum degassing process without heating), mixed good glue as possible within 8 hours.

3. Degassing is completed, the plastic material poured into the filling plastic syringes. To further drive out the air rubber, plastic material can be installed on the vacuum syringe bubble row again.

4 Glue, should first stand or pedestal preheated 150 ℃ / 1H above, to remove moisture inside the stand or base, in order to avoid air bubbles during curing.

5 curing conditions :80-100 ℃ / 1H +150 ℃ / 3H long roast

Note: You can adjust according to actual situation, but you must be thorough test compound packaging specifications A, B: 0.5Kg / bottle

Storage conditions Store in a cool dry and ventilated enclosed place (storage temperature -5 ~ 25 ℃, humidity ≤ 65%), waterproof, leak-proof, sunscreen, anti-high temperature, away from sources of ignition.

Shelf life 6 months

Precautions

Applications: 1.BQ-4370-1A / B using stored process must ensure that no phosphorus (P), sulfur (S), nitrogen (N), the organic tin (Sn), water, polyurethane resin, catalyst poisons, in order to avoid

Obstruction and deterioration caused by curing (eg: cleaning plastic cup of the solution, oven residual toxic ingredients, organic acids, etc.).

(2) If it is found at the bottom of a precipitate B agent turbidity, is a normal phenomenon, shake well before using.

Security: 1. Products should pay attention to protective wear, avoiding the construction process heat burns, prohibit the consumption.

(2) Be careful using this, Before and during use, please pay attention to safety issues. Furthermore, it should follow the relevant national or local government safety regulations. (Detailed safety instructions refer to the corresponding MSDS)

Disclaimer: This product catalog provides information entirely based on laboratory testing and practical experience gained understanding, we strive to accurately and believe that a high reference value. However, as the product is often used in conditions beyond our control, we can only guarantee the quality of the product itself. We reserve the right to modify without notice the specification right.
